Za sve vrste baterija-Solarni regulator LS1024R 12V/24V 10A
| Electrical parameters | LS1024R | LS2024R |
| Nominal System Voltage | 12 / 24VDC auto work | |
| Rated Battery Current | 10A | 20A |
| Max. Battery Voltage | 32V | |
| Charge Circuit Voltage Drop | ?0.26V | |
| Discharge Circuit Voltage Drop | ?0.15V | |
| Self-consumption | ?6mA | |
| Overall dimension | 140 x 65 x 34mm | 144 x 75x 45mm |
| Terminal | 4mm2 | 10mm2 |
| Net weight | 0.15kg | 0.25kg |
| Working temperature | -35? to +55? | |
| Humidity | 10%-90% NC | |
| Enclosure | IP30 | |
| Battery Voltage Parameters (temperature at 25?) | |||
| Battery charging setting | Gel | Sealed | Flooded |
| Equalize Charging Voltage | —— | 14.6V;x2/24V | 14.8V;x2/24V |
| Boost Charging Voltage | 14.2V;x2/24V | 14.4V;x2/24V | 14.6V;x2/24V |
| Float Charging Voltage | 13.8V;x2/24V | 13.8V;x2/24V | 13.8V;x2/24V |
| Low Voltage Reconnect Voltage | 12.6V;x2/24V | 12.6V;x2/24V | 12.6V;x2/24V |
| Low Voltage Disconnect Voltage | 11.1V;x2/24V | 11.1V;x2/24V | 11.1V;x2/24V |
| Equalize Duration | —— | 2 hours | 2 hours |
| Boost Duration | 2 hours | 2 hours | 2 hours |
